The cylinder piston rod is not just the object transmitting the force from the cylinder’s piston but also the interface between that cylinder and your machine. Before you can correctly select and then design the piston rod, you must understand the materials for cylinder piston rods. The following are the top  common piston rod materials on hydraulic cylinders . Most commonly, the cylinder piston rod is made of carbon steel or stainless steel like CK45, SAE1045, 4140, 4340, SAE1518,SAE4145,JIS45C, 40Cr, 20MnV6, 42CrMo, SS431, SS430, Stainless Steel 304/316/2205, etc.and is then coated with Hard Chrome Plating (HCP).Chrome plating not only offers durable long-term protection against corrosion, but also provides a smooth finish that can be ground and polished to a precise diameter. This is critical to optimizing seal performance and providing enough clearance to allow lubrication between the rod and seal, but not outright leakage. The  chrome plating used for hydraulic cylinder rods is

  What is the difference of chrome, nickel and stainless steel? Chrome is the short form for chromium. Chrome is metal core plated with a thin chromium veneer. Standard chrome hardware has a polished surface that shines like a mirror and reflects light in the same way. As such, surfaces of this nature show fingerprints and scratches more readily. There is also satin or brushed chrome, which gives the appearance of a matte surface. Chrome plating will not rust, however when it is damaged - it can appear dull. The metal core can rust if plating is lost through accidental damage or with natural wear over time. Nickel is metal core plated with a thin nickel veneer. Nickel  options can go from highly polished or satin finishes to having a darker, weathered, antique appearance. Nickel provides a toned down, softer look that often appears in transitional style kitchens. Though nickel is resistant to corrosion and wear, over time it can become dull and start to tarnish. Nickel is often lacq

  The Surface Treatment Of Hydraulic Cylinder Piston Rod Hydraulic cylinder piston rod  is the important part in  hydraulic cylinder built . The surface of the cylinder piston rod is one of the critical points in all hydraulic installations. An appropriate combination of base material and processing technology, along with the sealing system used in the corresponding hydraulic enviroment, is essential to optimize durability and cost-effectiveness. Depending on the application, we advise on the most appropriate treatment and quality of materials in any given application. Heat Treatment Type: 1) Normal no heat 2)Q+T(Quenched+Tempered) 3) Induction Hardened Quenching and tempering treatment The purpose of quenching and tempering treatment is to make the piston rod have comprehensive mechanical properties with good matching of strength, hardness, plasticity and toughness, which is ready for subsequent surface quenching. Surface hardening The piston rod moves fre

  Multi-stage telescopic cylinder is also called multistage hydraulic cylinder or telescopic hydraulic cylinder. It is composed of two or multiple stages of piston cylinder set, mainly composed of cylinder head, cylinder barrel , sleeve, cylinder rod and other parts. The characteristics of the multi-stage telescopic cylinder are: the working stroke can be very long, and it can be shortened when it is not working. Suitable for installation space is limited and travel requirements are very long occasions, such as tipping truck, telescopic boom crane. When the telescopic hydraulic cylinder is extended step by step, the effective working area decreases step by step. When the input flow rate is constant, the extension velocity increases gradually. When the external load is constant, the working pressure of the hydraulic cylinder increases gradually. The extension of the single-acting telescopic hydraulic cylinder depends on the oil pressure, and the contraction depends on the weight or l
